What Is Pipeline Buckling?

Buckling is the loss of stability of a pipeline under compression. In local buckling the pipe wall folds at one point. In global buckling the whole line moves out of its position, upwards or sideways. Both follow from loads along the pipe axis, which a pipeline is not designed for.

Talk to an expert

On this page

At a glanceCausesDetectionFAQ

Pipeline Buckling at a Glance

Local bucklingThe wall folds or wrinkles on the compressed side of a bend
Global bucklingThe line lifts out of the ground (upheaval) or moves sideways (lateral)
CausesGround movement, thermal expansion, too little depth of cover
Leads toReduced cross-section, cracks at the buckle, coating damage

What Causes a Pipeline to Buckle?

  • Ground movement: landslides and settlement bend the pipe and compress one side of it. See geotechnical hazards
  • Temperature and pressure: a hot line expands. If the soil cannot hold it, the line lifts where the cover is thin
  • Loss of cover: erosion or third-party work removes the soil that restrains the pipe

The quantity behind all three is strain. A buckle forms where the compressive strain exceeds what the pipe can take.

How Is Buckling Detected?

Inside the pipe, caliper pigs measure the shape of the cross-section, and tools with an inertial measurement unit record the bending strain. Both need a piggable line.

From above ground, EMPIT's Current Magnetometry Inspection (CMI) records the position of the pipe in 3D, the depth of cover and the bending strain along the route. This shows where the strain is high and where the cover is thin, also on unpiggable pipelines. See Bending Strain on Unpiggable Pipelines.

Frequently Asked Questions

What is the difference between local and global buckling?

In local buckling the pipe wall folds at one location. In global buckling the pipe keeps its cross-section but the whole line moves upwards or sideways.

What is upheaval buckling?

Upheaval buckling is global buckling in the vertical direction. A line that expands under temperature lifts out of the ground where the cover is too thin to hold it.

Is a buckle a defect that has to be repaired?

A buckle reduces the cross-section and concentrates strain. Whether it can stay is decided in an assessment of the strain and of the loads still acting on the line.

Start with a Pilot Section

If you want to know what ground movement has done to your line, send us the length, diameter and location of the pipeline. We will tell you whether CMI fits and what a pilot section would look like.

Get in touch

Sources

  • DNV-ST-F101, Submarine pipeline systems
  • INGAA Foundation, Guidelines for Management of Landslide Hazards for Pipelines, 2020
